Triple fitness rack HR301D (f.h. 1 m)

Technical specifications

Product code:	HR-301D-10
Weight:	47.85 kg
Recommended age:	3-15 years
Free fall height:	1 m
Load capacity:	162 kg
Maximum number of users:	3
Measurements:	3.7 x 0.1 x 1.06 m
Required area for assembly:	6.7 x 3.1 m
Fall damping surface:	Grass surface

The triple fitness rack support structure is made from 100 x 100 mm thick glued wooden supports. This solution ensures maximum protection against cracking, which is common for products made from solid wood. The wooden supports are impregnated and coated with a triple layer of lacquer, which meets the terms and conditions of the EN71/3 Standard (safe for children's toys). The structures are anchored into the ground in steel plates, which are protected against corrosion by hot-dip galvanizing and fixed in a concrete bed. The anchors are fastened to the play unit with bolts and their structure ensures that they are not in direct contact with the ground. All other metallic elements are also zinc coated and treated with baked paint KOMAXIT according to the RAL colour system. All fastening material is galvanized or stainless steel.
