Product code: PY-830K-10
Rope pyramid PY830K (f.h. 1 m, with 8 tension locks) - there is no need for a fall zone up to the height of 1 m, a grass surface is enough. More information
| Product code: | PY-830K-10 |
|---|---|
| Weight: | 86.13 kg |
| Recommended age: | 3-15 years |
| Free fall height: | 1 m |
| Load capacity: | 3024 kg |
| Maximum number of users: | 56 |
| Measurements: | 4.6 x 4.6 x 3 m |
| Required area for assembly: | 7.6 x 7.6 m |
| Fall damping surface: | Grass surface |
The support pillar of the rope pyramid is made from structural steel. The pillar is protected against corrosion by hot-dip galvanizing and fixed in a concrete bed. The ropes are made using HERKULES material (16 mm thick ropes made from polypropylene with a steel internal core) and are connected with plastic or aluminium joints. The turnbuckles are stainless steel. All fastening material is galvanized or stainless steel.
No comments or questions Rope pyramid PY830K (f.h. 1 m, with 8 tension locks) regarding this product. Do not hesitate to ask.
Technical sheet [170 kB, PDF]
